1220/1222/1223R-10 Rear Position and Stop Lights
1220/1222/1223R-10 Rear Position and Stop Lights
ECE certified for all included functions when mounted in the orientation shown
LumenX® lens
Built-in AMP-compatible receptacle for direct attachment to body harness or requires B417-49 or B817-49 plug
Dual voltage 12/24 V
IP67 rated
PM-1220R-10 flush mounts using B421-18 grommet or surface mounts using B820 series bracket
PM-1222R-10 & PM-1222RC-10 surface mount with bracket
PM-1223R-10 flange mounts
Relevant Market Sectors
Additional Information
Part Numbers
PM-1220R-10 – Rear position & stop light
PM-1222R-10 – Rear position & stop light, surface mount, black bracket
PM-1222RC-10 – Rear position & stop light, surface mount, chrome bracket
PM-1223R-10 – Rear position & stop light, flange mount
Accessories
PM-B820-09 – Black bracket for PM-1220R-10 (surface mounting)
PM-B820-10 – Chrome bracket for PM-1220R-10 (surface mounting)
PM-B421-18 – Grommet for PM-1220R-10 (for flush mounting)
PM-B417-49 – 3-wire plug
PM-B817-49 – 3-wire plug (moulded)
| Stop | Pos | Ind | Fog | Rev | Num | Mrkr | Reflex |
|---|---|---|---|---|---|---|---|
| ✓ | ✔︎ |
